Description
Description
TYPE
Long stroke air brake chamber Type 3030 designed to deliver increased braking force and consistent performance in heavy-duty air brake systems.
REPLACEMENT FOR
Haldex: GC3030L, LC3030L, GC3030LR
Bendix: NT3030ELS80, NT3030ELS99
Midland: 3030054, MBI GC3030LR
Automann: 179.SB3030SL
Watson & Chalin: 12963
SPECIFICATIONS
Actuator Type Size: 3030
Stroke Type: Long
Available Stroke: 3" (76 mm)
Length (Mounting Bracket to End of Spring Housing): 9-7/8" (251 mm)
Length of Piggyback: 7-3/8" (187 mm)
Rolled Spring Housing Flange Dimension: 8-5/16" (211 mm)
Service Clampband Dimension: 10-3/16"
Pushrod Length (from face of Service Housing): 13"
Weight: 21.8 lbs (9.9 kg)
FEATURES
Built with superior power spring technology and an advanced powder coating process to resist corrosion and fatigue. Features a double O-ring center seal with plastic bearings for long service life. Includes a world-class diaphragm made from high-quality rubber compound resistant to heat and cold, a rugged 9-gauge steel service housing, and a self-piloting dust shield for added protection.
WARRANTY
Covered by a 1-year unlimited mile warranty, providing quality assurance and replacement coverage if an issue occurs within the warranty period.
